NOTICE: This vehicle has many variables when replacing the radio, READ (we repeat READ) the notes below:

Dash Kit Note: KIT-F150 works on 2013-2014 ONLY when equipped with 4.3" MyFord radio, this kit INCLUDES the required Maestro harness, but you must ADD Maestro RR or RR2, and you MUST have a Maestro capable radio.
99-5820 works on 2009 - 2014 and can be used on NON navigation vehicles only (meaning did not come with nav from Ford)

Interface Note: To determine which interface to use, ask the following questions:

(FYI: FD1 is for 2009 - 2011, FD2 is for 2012 - Up)

Does the vehicle have SYNC?
Yes = ADS-MRR/MRR2 or AXDIS-FD1 or FD2
No = ADS-MRR/MRR2 or AXTC-FD1 or FD2

Does the vehicle have SAT radio (from Ford)?
Yes = ADS-MRR/MRR2 or AXDIS-FD1 or FD2
No = ADS-MRR/MRR2 or AXTC-FD1 or FD2

Does the vehicle have RSE (rear seat entertainment)?
Yes = ADS-MRR/MRR2 or AXDIS-FD1 or FD2
No = ADS-MRR/MRR2 or AXTC-FD1 or FD2

Harness Note:To determine which harness to use, see below:

70-5520 is basic wire harness for 2009 - 2011
70-5524 is basic wire harness for 2012 - 2014

HRN-RR-FO1 is Maestro harness for 2009 - 2011 (5520 shell)
HRN-RR-FO2 is Maestro harness for 2012 - 2014 (5524 shell)

FD1 (from Axxess) is for 2009 - 2011
FD2 (from Axxess is for 2012 - 2014
